Model:
PF-3110
Type:
Paper Feeder
Capacity (sheets):
500 sheets
Dimensions (W x D x H):
(W x D x H) 92 – 216 x 162 – 356 mm
Paper size:
60 – 120g/m2, A4, A5, B5, Letter, Legal Custom
TK-3165
Microfine toner black for 12,500 pages A4. Capacity of starter toner is 6,000 pages, A4. Average continuous toner yield in accordance with ISO/IEC 19752.
MD3-1024
1,024 MB RAM Expansion
MDDR3-2GB
2,048 MB RAM Expansion
HD-6
32 GB SSD hard disc for easy document management
HD-7
128 GB SSD hard disc for easy document management
IB-36
Direct Wi-Fi Interface
IB-50
Gigabit-Ethernet board 10BaseT/100BaseTX/ 1000BaseT
USB IC Card Reader + Card Authentication Kit (B)
Support for various authentication keys available
UG-33
ThinPrint support
Data Security Kit (E) AC
In line with ISO 15408 (Common Criteria) with security level EAL3. HD-6, HD-7 or SD-card is needed”
General type
Colour multifunctional for up to SRA3 format
Technology
KYOCERA ECOSYS, Laser, Black & White
Engine speed
Up to 35 pages A4 per minute, Up to 17 pages A3 per minute, Duplex print speed: 35 pages per minute, A4 Duplex copy speed: 35 pages per minute, A4
Resolution
1200 x 1200 dpi (print), 600 x 600 dpi (copy/scan)
Warm-up time
Approx. 18 seconds or less
Time to first page
Approx. 7 secs. or less (platen/DP)
Dimensions (W x D x H)
475 x 476 x 575 mm
Weight
Approx. 22.3 kg
Power consumption
Printing: 667W, Copying: 683W, Low Power mode: 29W, Ready mode: 50W, Sleep mode: 0.5W
Power source
AC 220 ~ 240 V, 50/60 Hz
Noise (ISO 7779)
Copying/Printing: 54 dB(A) Stand-by mode: 30 dB(A)
Safety standards
TUV/GS, CE – This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.
General memory
Standard: 1 GB RAM, Max with options: 3 GB + optional 32GB or 128GB Hard Disk
Input capacity
Multi-purpose tray: 100 sheets, 60–220g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 148 to 216 x 356 mm). Standard universal paper cassette: 500 sheet, 60–120 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (140 x 148 to 216 x 356 mm).
Max. input capacity with options
2,600 sheets A4
Duplex unit
Standard duplex unit, 60-120 g/m2 , A4, A5, B5, Letter, Legal
Max. output capacity
250 sheets face down
General paper handling
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions
N/A
Processor
ARM Cortex-A9 Dual core 1.2 GHZ + ARM Cortex-M3 100 MHZ
Controller language
PRESCRIBE IIc
Emulations
PCL6 (5c/XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print, AES support, TIFF/JPEG Direct Print Support, Open XPS, Line Printer, IBM Proprinter X24E, Epson LQ-850
Fonts
93 outline fonts (PCL6/KPDL 3), 8 fonts (Windows), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Integrated Accounting
100 department codes
Features
PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3
Mobile printing support
KYOCERA Mobile Print app for IOS and Android, KYOCERA MyPanel, Airprint, Mopria, Direct WIFI (option)
Standard Interfaces
USB 2.0 (Hi-Speed), 2 x USB Host 2.0, GigaBit Ethernet (10BaseT / 100Base-TX / 1000 BaseT, Ipv6, Ipv4, IPsec), optional WIFI (IEEE 802.11b/g/n), 1 eKUIO slot for optional internal print server, slot for optional SD card
Applicable OS
All current Windows operating systems, MAC OS X Version 10.8 or higher, Unix, Linux”
Max. original size
A4/Legal
Digital copy features
Scan-once-copy-many, electronic sort (collate), ID card copy, 2in1, 4in1, auto cassette change, Skip blank page
Exposure modes
Auto, manual: 9 steps
Preset magnification ratios
7 Reductions/5 Enlargements
Zoom range
25 – 400 % in 1% steps
Continuous copy
1 – 999
Image adjustments
Text + Photo, Photo, Text, Chart/Map, Printed document
Interfaces
Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT),
File type
TIFF, PDF, PDF/A, JPEG, XPS, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u
Original recognition
Text, photo, text + photo, light text, optimized for OCR
Max. scan size
A4/Legal
Scan functionalities
Scan-to-Email, Scan-to-FTP , Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan
Scan resolution
600, 400, 300, 200 dpi, 256 greyscales per colour
Scan speed
60 ipm (300 dpi, A4, b/w) 40 ipm (300 dpi, A4 colour) 26 ipm (300 dpi, A4, b/w) (Duplex) 17 ipm (300 dpi, A4 colour) (Duplex)
Compatibility
ITU-T Super G3
Modem speed
Max. 33.6 kbps
Transmission speed
Max: 3 secs. (JBIG)
Scanning density
Normal: 8 dot/mm x 3.85 line/mm (200 x 100 dpi) Fine: 8 dot/mm x 7.7 line/mm (200 x 200 dpi) Superfine: 8 dot/mm x 15.4 line/mm (200 x 400 dpi) Ultrafine: 16 dot/mm x 15.4 line/mm (400 x 400 dpi) Halftone: 256 grey scales
Max. original size
A4, Legal
Compression method
JBIG, MMR, MR, MH
Fax features
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
