Bring power and performance to high quality printing at speeds up to 60 pages per minute. Easily tackles complex printing and day to day business requirements with ease.
High speeds up to 60 ppm b&w
9″ color TSI – intuitive user interface
| Input capacity | Multi-purpose tray: 150 sheets. 52–300 g/m2, Banner 135-165 g/m2 , A6R-SRA3 (320 x 450mm) Tab paper (136 x 256g/m2) Banner max 320 x 1220mm, Standard universal cassette: 2 x 500 sheet, 52-300 g/m2. Upper cassette: A6R up to A4R (320 x 450mm), |
| Max. input capacity with options | 7,150 sheets A4 |
| Duplex unit | Duplex as standard supports 60-256 g/m²; SRa3 to A6R, Letter/LetterR, Folio, Oficio2, Legal , Ledger |
| Max. output capacity | 5000 sheets face-down with paper full sensor detection |
| General paper handling | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. |
| TK-6335K | Toner Black for 32,000 pages. Average continuous toner yield in accordance with ISO/IEC 19752.
Starter toner Capacity is 16,000 pages |
| PF-7100 | Paper Feeder: 2 x 500 sheets, 52–300 g/m², A6R–SRA3 (320 x 450 mm), folio |
| PF-7110 | Paper Feeder: 2 x 1,500 sheets, 52-300 g/m², A4, B5, letter |
| PF-7120 | A4 side deck: 3,000 sheets, 60–300 g/m², A4, B5, Letter |
| DF-7110 | Document Finisher (AK-7110 required): Main tray, 4,000 sheets, A4 (3,000 sheets with attachment BF-730) 52-300g/m2, A6R-SRA3, Subtray: 200 sheets A4, 52-300g/m2, A6R-SRA3, 100 sheets 52-300g/m2, A6R-SRA3. Stapling up to 65 sheets A4 or 30 sheets A3 at 3 positions, B5-SRA3 |
| DF-7120 | Document Finisher (AK-7110 required), Main tray: Max. 1,000 sheets A4 52-300g/m2, A6R-SRA3 , 3 positions stapling up to 50 sheets A4 or 30 sheets SRA3 |
| AK-7100 | Attachment kit for DF-7110 |
| PH-7C | Punch Unit, 2-hole / 4-hole, 60-300 g/m², A5R–A3 for DF-7120/DF-7110 |
| SH-10 | 5000 X 3 Staples: for BF-730, DF-7100, DF-7120 |
| SH-12 | 5000 X 3 Staples: for DF-7110 |
| Banner Guide (10) | Banner paper feeding guide, 10 sheets, 320 x 1 220 mm |
| BF-730 | Booklet and tri-folding unit for DF-7140, Half folding: 60–256 g/m², A3, B4, A4R Booklet: max. 16 sheets (64 pages, 60–90 g/m²) Non-staple |
| JS-7100 | Job separator, 100 sheets, 52 – 300 g/m², A5R – SRA3 |
| MT-730(B) | Mailbox sorter for DF-7140,7 bins x 100 sheets A4, 50 sheets A3/B4,60–163 g/m² |
| IB-35 | Wireless Network Interface (USB: 2.4GHz) |
| IB-50 | Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT |
| Data Security Kit (e) AC | Encrypts data stored on SSD/HDD in line with ISO 15408 (common criteria) with security Level EAL2 |
| NK-7100 (B) | Numeric keypad |
| UG-33 | ThinPrint support |
| UG-34 | Emulation (IBM Proprinter?EPSON LQ-850/Line Printer) |
| USB IC Card Reader + Card Authentication Kit (B) | Support for various authentication keys available |
| General type | Monochrome Laser Printer for A3 format |
| Engine speed | Up to 60/30 pages A4/A3 per minute |
| Resolution | 1,200 x 1,200 dpi (print), 600 x 600 dpi(scan/copy) |
| Warm-up time | Approx. 17 seconds or less |
| Time to first print | Approx. 3.8 seconds or less in mono/color |
| Dimensions (W x D x H) | 602 x 665 x 790 mm |
| Weight | Approx. 77.2 kg |
| Power consumption | Printing/Copying: 820W, Ready mode: 40W,
Sleep mode: 1.0W |
| Power source | AC 220 ~ 240 V, 50/60 Hz |
| Noise (ISO 7779 (Sound pressure level) | Printing/Copying: 55.8 dB(A)/ Standby: 32.4 dB |
| Safety standards | TUV/GS, CE – This unit is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| General memory | Standard 4GB + 8GB SSD + 320GB HDD |
| Standard interface | 4 x USB 2.0 (High Speed USB), USB Host 2.0 , Fast Ethernet (10BASE-T/100BASE-TX/1000BASE-T), slot for optional print server, slot for optional SD card |
| Input capacity | Multi-purpose tray: 150 sheets. 52–300 g/m2, Banner 135-165 g/m2 , A6R-SRA3 (320 x 450mm) Tab paper (136 x 256g/m2) Banner max 320 x 1220mm, Standard universal cassette: 2 x 500 sheet, 52-300 g/m2. Upper cassette: A6R up to A4R (320 x 450mm), |
| Max. input capacity with options | 7,150 sheets A4 |
| Duplex unit | Duplex as standard supports 60-256 g/m²; SRa3 to A6R, Letter/LetterR, Folio, Oficio2, Legal , Ledger |
| Max. output capacity | 5000 sheets face-down with paper full sensor detection |
| General paper handling | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. |
| Processor | Freescale QorIQ T1024 (Dual Core)1.2 GHz |
| Controller language | PRESCRIBE |
| Emulations | PCL 6 (5c/XL), KPDL 3 (PostScript 3 compatible), PDF Direct Print XPS/Open XPS Direct Print, and OpenXPS |
| Fonts/barcodes | 93 outline fonts (PCL) 136 fonts , KPDL3), 4 fonts (Calibri), 4 fonts (Cambria), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417) |
| Integrated Accounting | 1,000 department codes |
| Applicable OS | All current Windows operating systems, MAC OS X Version 10.8 or higher, Chrome OS, Linux, Unix |
