| Input capacity | 50-sheet multi-purpose tray, 60–220 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Custom (70 x 148 to 216 x 356 mm), 250-sheet universal paper cassette, 60–163 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm). |
| Max. input capacity with options | 550 sheets |
| Duplex unit | Standard duplex unit: 60-120 g/m²; A4, A5, B5, Letter, Legal |
| Max. output capacity | 150 sheets face-down with paper full sensor |
| General paper handling | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions. |
| TK-5244K | Average continuous black toner yield 4,000 pages in accordance with ISO /IEC 19798. Average continuous black toner yield 1,200 pages in accordance with ISO /IEC 19798 (starter toner) |
| TK-5244C | Average continuous cyan toner yield 3,000 pages in accordance with ISO /IEC 19798. Average continuous cyan toner yield 1,200 pages in accordance with ISO /IEC 19798 (starter toner) |
| TK-5244M | Average continuous magenta toner yield 3,000 pages in accordance with ISO /IEC 19798. Average continuous magenta toner yield 1,200 pages in accordance with ISO /IEC 19798 (starter toner) |
| TK-5244Y | Average continuous yellow toner yield 3,000 pages in accordance with ISO /IEC 19798. Average continuous yellow toner yield 1,200 pages in accordance with ISO /IEC 19798 (starter toner) |
| DK-5230 | Drum life is 100,000 pages |
| UG-33 | ThinPrint support |
| Data Security Kit (E) AC | In line with ISO 15408 (Common Criteria) with security level EAL3 |
| USB IC Card Reader + Card Authentication Kit (B) | Support for various authentication keys available |
| PF-5110 | Paper Feeder 60–163 g/m2; A4, A5, B5, Letter, Legal, Custom (148 x 210 mm–216 x 356 mm) | 250 sheets |
| General type | Colour Laser Printer for A4 format |
| Technology | KYOCERA ECOSYS, Colour Laser |
| Engine speed | Up to 26 pages A4 per minute in colour and B/W |
| Resolution | 1200 x 1200 dpi (print, at reduced speed), multibit technology for print quality of up to 9,600 x 600 dpi (print), 600 x 600 dpi |
| Warm-up time | Approx. 29 seconds or less from power on |
| Time to first print | Approx. 9.5/10.5 seconds or less in B/W / colour |
| Dimensions (W x D x H) | 410 x 410 x 329 mm |
| Weight | Main unit: Approx. 21 kg |
| Power consumption | Printing: 375W, Ready mode: 33W, Sleep mode: 0.9W |
| Power source | AC 220 ~ 240 V, 50/60 Hz |
| Noise (ISO 7779) | Noise (Sound pressure level: ISO 7779/ISO 9296) Printing in colour: 49 dB(A) LpA, Ready/Stand-by: 30 dB (A) LpA, Sleep-mode: Immeasurable low |
| Safety standards | TUV/GS, CE – This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| General memory | Standard 512mB RAM, Max. 512M RAM |
| Standard interface | USB 2.0 (Hi-Speed), USB Host Inter-face, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT), Wireless LAN, Slot for optional SD/SDHC-Card |
| Input capacity | 50-sheet multi-purpose tray, 60–220 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Custom (70 x 148 to 216 x 356 mm), 250-sheet universal paper cassette, 60–163 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm). |
| Max. input capacity with options | 550 sheets |
| Duplex unit | Standard duplex unit: 60-120 g/m²; A4, A5, B5, Letter, Legal |
| Max. output capacity | 150 sheets face-down with paper full sensor |
| General paper handling | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions. |
| Processor | Cortex-A9 800MHz |
| Controller language | PRESCRIBE IIc |
| Emulations | PCL 6 (5c/XL), KPDL 3 (PostScript 3 compatible), PDF Direct Print 1.7, XPS Direct Print |
| Fonts | 93 scalable fonts for PCL/PostScript, 8 fonts for Windows Vista, 1 Bitmap font, 45 barcodes (e.g. EAN8, EAN13, EAN128) with automatic generation of checksums as well as support for two-dimensional barcodes PDF-417 under PRESCRIBE (PCL and other barcodes available as an option) |
| Integrated Accounting | 20 department codes |
| Features | Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality |
| Protocol | Mobile printing support: KYOCERA Mobile Print app for iOS and Android, Airprint, Mopria |
| Applicable OS | All current Windows operating systems, MAC OS X Version 10.8 or higher, Unix, Linux |
